The above photo is showing screws and nuts used for the mounting of the brushless motors,and a rubber is used to suppress the vibrations
The above picture is showing the motor mounted on the carbon fiber rod....with the help of aluminium plates
The picture is showing the rubber between the carbon fiber rod and the motor.Rubber is used to supress the vibrations and to give proper strength to carbon fiber rod ,so that we can easily tighten the screws without breaking the carbon fiber rods
Motor is mounted on carbon fiber rods with the supports of aluminium plates connected which we drilled according to the threads and holes available in the brushless motors and a rubber is inserted between the motor and the carbon fiber rods ,so that carbon fiber rod do not break and vibrations could be reduced.
Carbon fiber rods are fragile in nature perpendicular to the threads but it is very tough and give great strength along the threads.
It is not advised to drill a whole directly into carbon fiber rods because it could just spread the carbon fiber rod from there ,and will be of no use .Same is the case when u r cutting it .So we should be very careful while cutting the rods as this is very costly .
The another thing that u can use to drill into carbon fiber rod is , just use some hot pin point thing ,in this way your carbon fiber rod will not spread out and you can make a hole into that.
